Rotel RB-1552 MkII 130 Watt Stereo Power Amplifier
Rotel
RB-1552 MkII 130 Watt Stereo Power Amplifier
The RB-1552 MkII is a 130 Watt per channel class AB amplifier. It is engineered to be powerful and robust, yet able to extract every last nuance out of even the most complex musical score.
Notable features of the amplifier include independent left and right power rectification stages and decoupling. The layout is essentially a mono block design. Further evidence of design over-spec is in the selection of premium “slit-foil” capacitors, which provide plenty of reserve energy for extremely dynamic audio passages and are able to quickly replenish themselves due to the nature of their unique design. Input options are balanced XLR or unbalanced RCA connectors.
| Continuous Power Output |
130 W/Ch (20-20kHz, <0.03%, 8 Ohms) |
| Amplifier Class | AB |
| Total Harmonic Distortion | <0.03% (20-20kHz, 8 Ohms) |
| Damping Factor | 450 (20-20kHz, 8 Ohms) |
| Input Impedance (Unbalanced) |
12k Ohms |
| Input Impedance (Balanced) | 100k Ohms |
| Input Sensitivity (Unbalanced) |
1.5 Volt |
| Input Sensitivity (Balanced) | 2.5 Volt |
| Frequency Response | 10Hz-100kHz (+/- 0.5dB) |
| Signal to Noise Ratio | 120dB |
| Speaker Impedance |
4 Ohms Minimum |
| Gain (Unbalanced) |
26.5dB |
| Gain (Balanced) | 22.5dB |
| Dimensions (WxHxD) | 17" x 5 7/8" x 13 3/8" (431mm x 144mm x 339mm) |
| Panel Height | 3U, 5 1/4" (132.6mm) |
| Weight | 27.27lbs (12.4kg) |
